VTX20 Elegant Tab Mount 1 ½" (38mm) Core
38mm (1 ½") Tube - 1 ½" (38mm) Projection Brackets
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-380XX | 1 ½" (38 mm) Aluminum Tube 0-154-TU-380XX 1 ½" (38 mm) Aluminum Tube
 FT
0-000-07-XXXXX | PolyscreenVision 550 Crystal Vertical 0-000-07-XXXXX PolyscreenVision 550 Crystal Vertical
(Optional) 		YD
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-BX-56038 | Installation Brackets | Large TM | 1½" (38mm) Projection 0-154-BX-56038 Installation Brackets | Large TM | 1½" (38mm) Projection
 1 SET
38mm (1 ½") Tube - 2" (50mm) Projection Hybrid Bracket
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-380XX | 1 ½" (38 mm) Aluminum Tube 0-154-TU-380XX 1 ½" (38 mm) Aluminum Tube
 FT
0-000-07-XXXXX | PolyscreenVision 550 Crystal Vertical 0-000-07-XXXXX PolyscreenVision 550 Crystal Vertical
(Optional) 		YD
0-155-EX-SLE53 | HM End Plug 1½" (38mm) | Spring Loaded 0-155-EX-SLE53 HM End Plug 1½" (38mm) | Spring Loaded
 1 EA
0-154-BX-TM020 | Easy-Tab Bracket | Large Tab | 2" (50mm) Projection 0-154-BX-TM020 Easy-Tab Bracket | Large Tab | 2" (50mm) Projection
 1 EA
0-155-BX-SL020 | Installation Bracket | HM | 2" (50mm) Projection 0-155-BX-SL020 Installation Bracket | HM | 2" (50mm) Projection
 1 EA
0-155-CO-SL20X | Cover for HM Installation Braket with 2" (50mm) Projection 0-155-CO-SL20X Cover for HM Installation Braket with 2" (50mm) Projection
 2 EA
0-155-BX-SLI20 | Intermediate Bracket | HM | 2" (50mm) Projection 0-155-BX-SLI20 Intermediate Bracket | HM | 2" (50mm) Projection
(Optional) 		1 EA
45mm (1 ¾") Tube - Structural Tube & 2" (50mm) Projection Brackets
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-46010 | 45mm (1 ¾") Heavy Duty Structural Tube for 1 ½" (38 mm) 0-154-TU-46010 45mm (1 ¾") Heavy Duty Structural Tube for 1 ½" (38 mm)
 FT
0-154-AD-00045 | Adapter for 45 mm Heavy Duty Structural Tube, End Plug Side 0-154-AD-00045 Adapter for 45 mm Heavy Duty Structural Tube, End Plug Side
 1 EA
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-BX-58050 | Installation Brackets | Large TM | 2" (50mm) Projection 0-154-BX-58050 Installation Brackets | Large TM | 2" (50mm) Projection
 1 SET
0-154-CO-580X0 | Cover for Large TM Installation Braket with 2"(50mm) Projection 0-154-CO-580X0 Cover for Large TM Installation Braket with 2"(50mm) Projection
 1 SET
50mm (2") Tube - 2" (50mm) Projection Brackets
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-501XX | 2" (50 mm) Grooved Aluminum Tube 0-154-TU-501XX 2" (50 mm) Grooved Aluminum Tube
 FT
0-000-07-XXXXX | PolyscreenVision 550 Crystal Vertical 0-000-07-XXXXX PolyscreenVision 550 Crystal Vertical
(Optional) 		YD
0-154-AD-XA250 | Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30 0-154-AD-XA250 Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30
 2 EA
0-154-BX-58050 | Installation Brackets | Large TM | 2" (50mm) Projection 0-154-BX-58050 Installation Brackets | Large TM | 2" (50mm) Projection
 1 SET
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-CO-580X0 | Cover for Large TM Installation Braket with 2"(50mm) Projection 0-154-CO-580X0 Cover for Large TM Installation Braket with 2"(50mm) Projection
 1 SET
50mm (2") Tube - 2" (50mm) Projection Hybrid Bracket
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-501XX | 2" (50 mm) Grooved Aluminum Tube 0-154-TU-501XX 2" (50 mm) Grooved Aluminum Tube
 FT
0-000-07-XXXXX | PolyscreenVision 550 Crystal Vertical 0-000-07-XXXXX PolyscreenVision 550 Crystal Vertical
(Optional) 		YD
0-154-AD-XA250 | Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30 0-154-AD-XA250 Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30
 2 EA
0-154-BX-TM020 | Easy-Tab Bracket | Large Tab | 2" (50mm) Projection 0-154-BX-TM020 Easy-Tab Bracket | Large Tab | 2" (50mm) Projection
 1 EA
0-155-BX-SL020 | Installation Bracket | HM | 2" (50mm) Projection 0-155-BX-SL020 Installation Bracket | HM | 2" (50mm) Projection
 1 EA
0-155-EX-SLE53 | HM End Plug 1½" (38mm) | Spring Loaded 0-155-EX-SLE53 HM End Plug 1½" (38mm) | Spring Loaded
 1 EA
0-155-CO-SL20X | Cover for HM Installation Braket with 2" (50mm) Projection 0-155-CO-SL20X Cover for HM Installation Braket with 2" (50mm) Projection
 2 EA
0-155-BX-SLI20 | Intermediate Bracket | HM | 2" (50mm) Projection 0-155-BX-SLI20 Intermediate Bracket | HM | 2" (50mm) Projection
(Optional) 		1 EA
63mm (2 ½") Tube - 50mm (2") Projection Brackets
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-630XX | 2 ½" (63 mm) Aluminum Tube 0-154-TU-630XX 2 ½" (63 mm) Aluminum Tube
 FT
0-000-07-XXXXX | PolyscreenVision 550 Crystal Vertical 0-000-07-XXXXX PolyscreenVision 550 Crystal Vertical
(Optional) 		YD
0-156-AX-GA025 | Adapter for 2 ½" (63mm) Tube 0-156-AX-GA025 Adapter for 2 ½" (63mm) Tube
2 EA
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-BX-58050 | Installation Brackets | Large TM | 2" (50mm) Projection 0-154-BX-58050 Installation Brackets | Large TM | 2" (50mm) Projection
 1 SET
0-154-CO-580X0 | Cover for Large TM Installation Braket with 2"(50mm) Projection 0-154-CO-580X0 Cover for Large TM Installation Braket with 2"(50mm) Projection
 1 SET
63mm (2 ½") Tube - 50mm (2") Projection Hybrid Bracket
Picture Code Description Quantity Unit
0-154-CL-V20XX | VTX20 Elegant Tab Mount 1 ½" (38mm) Core 0-154-CL-V20XX VTX20 Elegant Tab Mount 1 ½" (38mm) Core
 1 EA
0-154-TU-630XX | 2 ½" (63 mm) Aluminum Tube 0-154-TU-630XX 2 ½" (63 mm) Aluminum Tube
 FT
0-000-07-XXXXX | PolyscreenVision 550 Crystal Vertical 0-000-07-XXXXX PolyscreenVision 550 Crystal Vertical
(Optional) 		YD
0-156-AX-GA025 | Adapter for 2 ½" (63mm) Tube 0-156-AX-GA025 Adapter for 2 ½" (63mm) Tube
2 EA
0-155-EX-SLE53 | HM End Plug 1½" (38mm) | Spring Loaded 0-155-EX-SLE53 HM End Plug 1½" (38mm) | Spring Loaded
 1 EA
0-154-BX-TM020 | Easy-Tab Bracket | Large Tab | 2" (50mm) Projection 0-154-BX-TM020 Easy-Tab Bracket | Large Tab | 2" (50mm) Projection
 1 EA
0-155-BX-SL020 | Installation Bracket | HM | 2" (50mm) Projection 0-155-BX-SL020 Installation Bracket | HM | 2" (50mm) Projection
 1 EA
0-155-CO-SL20X | Cover for HM Installation Braket with 2" (50mm) Projection 0-155-CO-SL20X Cover for HM Installation Braket with 2" (50mm) Projection
 2 EA
0-155-BX-SLI20 | Intermediate Bracket | HM | 2" (50mm) Projection 0-155-BX-SLI20 Intermediate Bracket | HM | 2" (50mm) Projection
(Optional) 		1 EA
VTX20 Designer Tab Mount 1 ½" (38mm) Core
38mm (1 ½") Tube - Option 1: 38mm (1 ½") Projection Brackets
Picture Code Description Quantity Unit
0-154-TU-380XX | 1 ½" (38 mm) Aluminum Tube 0-154-TU-380XX 1 ½" (38 mm) Aluminum Tube
 FT
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-BX-56038 | Installation Brackets | Large TM | 1½" (38mm) Projection 0-154-BX-56038 Installation Brackets | Large TM | 1½" (38mm) Projection
 1 SET
38mm (1 ½") Tube - Option 2: 50mm (2") Projection Brackets
Picture Code Description Quantity Unit
0-154-TU-380XX | 1 ½" (38 mm) Aluminum Tube 0-154-TU-380XX 1 ½" (38 mm) Aluminum Tube
 FT
0-155-EX-SLE53 | HM End Plug 1½" (38mm) | Spring Loaded 0-155-EX-SLE53 HM End Plug 1½" (38mm) | Spring Loaded
 1 EA
0-154-BX-TM020 | Easy-Tab Bracket | Large Tab | 2" (50mm) Projection 0-154-BX-TM020 Easy-Tab Bracket | Large Tab | 2" (50mm) Projection
 1 EA
0-155-BX-SL020 | Installation Bracket | HM | 2" (50mm) Projection 0-155-BX-SL020 Installation Bracket | HM | 2" (50mm) Projection
 1 EA
0-155-CO-SL20X | Cover for HM Installation Braket with 2" (50mm) Projection 0-155-CO-SL20X Cover for HM Installation Braket with 2" (50mm) Projection
 2 EA
45mm (1 ¾") Tube - Option 1: Structural Tube - Internal Diameter: 38mm (1 ½")
Picture Code Description Quantity Unit
0-154-AD-00045 | Adapter for 45 mm Heavy Duty Structural Tube, End Plug Side 0-154-AD-00045 Adapter for 45 mm Heavy Duty Structural Tube, End Plug Side
 1 EA
0-154-TU-46010 | 45mm (1 ¾") Heavy Duty Structural Tube for 1 ½" (38 mm) 0-154-TU-46010 45mm (1 ¾") Heavy Duty Structural Tube for 1 ½" (38 mm)
 FT
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-BX-58050 | Installation Brackets | Large TM | 2" (50mm) Projection 0-154-BX-58050 Installation Brackets | Large TM | 2" (50mm) Projection
 1 SET
0-154-CO-580X0 | Cover for Large TM Installation Braket with 2"(50mm) Projection 0-154-CO-580X0 Cover for Large TM Installation Braket with 2"(50mm) Projection
 1 SET
45mm (1 ¾") Tube - Option 2: Double Insert Tube, 38mm (1 ½") Projection Brackets
Picture Code Description Quantity Unit
0-154-TU-452XX | 1¾" (45mm) Tube (Two Channels) 0-154-TU-452XX 1¾" (45mm) Tube (Two Channels)
 FT
0-154-PA-XXX01 | End Plug Adapter for 1 3/4" (45mm) Tube 0-154-PA-XXX01 End Plug Adapter for 1 3/4" (45mm) Tube
 1 EA
0-154-PE-XXX01 | End Plug for Euro Brackets 1½" (38mm) 0-154-PE-XXX01 End Plug for Euro Brackets 1½" (38mm)
 1 EA
0-154-PB-E04XX | EURO Medium Bracket | Large TM | 2" (50mm) Projection 0-154-PB-E04XX EURO Medium Bracket | Large TM | 2" (50mm) Projection
 1 EA
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 1 EA
0-154-PC-E01XX | Cover for EURO Medium Bracket 0-154-PC-E01XX Cover for EURO Medium Bracket
 2 EA
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 2 EA
45mm (1 ¾") Tube - Option 2: Double Insert Tube, 50mm (2") Projection Brackets
Picture Code Description Quantity Unit
0-154-TU-46010 | 45mm (1 ¾") Heavy Duty Structural Tube for 1 ½" (38 mm) 0-154-TU-46010 45mm (1 ¾") Heavy Duty Structural Tube for 1 ½" (38 mm)
 FT
0-154-PA-XXX01 | End Plug Adapter for 1 3/4" (45mm) Tube 0-154-PA-XXX01 End Plug Adapter for 1 3/4" (45mm) Tube
 1 EA
0-154-PE-XXX01 | End Plug for Euro Brackets 1½" (38mm) 0-154-PE-XXX01 End Plug for Euro Brackets 1½" (38mm)
 1 EA
0-154-PB-E06XX | EURO Large Bracket | Large TM | 2⅜" (60mm) Projection 0-154-PB-E06XX EURO Large Bracket | Large TM | 2⅜" (60mm) Projection
 1 EA
0-154-PB-E05XX | EURO Large Bracket | HM | 2⅜" (60mm) Projection 0-154-PB-E05XX EURO Large Bracket | HM | 2⅜" (60mm) Projection
 1 EA
0-154-PC-E02XX | Cover for EURO Large Bracket 0-154-PC-E02XX Cover for EURO Large Bracket
 2 EA
0-154-PC-004XX | Screw Cover for EURO Large Bracket 0-154-PC-004XX Screw Cover for EURO Large Bracket
 2 EA
50mm (2") Tube - Option 1: 50mm (2") Projection Brackets
Picture Code Description Quantity Unit
0-154-AD-XA250 | Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30 0-154-AD-XA250 Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30
 2 EA
0-154-EX-00038 | TM End Plug 1½" (38mm) 0-154-EX-00038 TM End Plug 1½" (38mm)
 1 EA
0-154-BX-58050 | Installation Brackets | Large TM | 2" (50mm) Projection 0-154-BX-58050 Installation Brackets | Large TM | 2" (50mm) Projection
 1 SET
0-154-CO-580X0 | Cover for Large TM Installation Braket with 2"(50mm) Projection 0-154-CO-580X0 Cover for Large TM Installation Braket with 2"(50mm) Projection
 1 SET
0-154-TU-500XX | 2" (50 mm) Aluminum Tube 0-154-TU-500XX 2" (50 mm) Aluminum Tube
 FT
50mm (2") Tube - Option 2: 50mm (2") Projection Brackets
Picture Code Description Quantity Unit
0-154-TU-500XX | 2" (50 mm) Aluminum Tube 0-154-TU-500XX 2" (50 mm) Aluminum Tube
 FT
0-154-AD-XA250 | Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30 0-154-AD-XA250 Adapter for 2” (50mm) Tube for VTX17, VTX20 & VTX30
 1 EA
0-155-EX-SLE53 | HM End Plug 1½" (38mm) | Spring Loaded 0-155-EX-SLE53 HM End Plug 1½" (38mm) | Spring Loaded
 1 EA
0-154-BX-TM020 | Easy-Tab Bracket | Large Tab | 2" (50mm) Projection 0-154-BX-TM020 Easy-Tab Bracket | Large Tab | 2" (50mm) Projection
 1 EA
0-155-BX-SL020 | Installation Bracket | HM | 2" (50mm) Projection 0-155-BX-SL020 Installation Bracket | HM | 2" (50mm) Projection
 1 EA
0-155-CO-SL20X | Cover for HM Installation Braket with 2" (50mm) Projection 0-155-CO-SL20X Cover for HM Installation Braket with 2" (50mm) Projection
 2 EA
50mm (2") Tube - Option 3: 38mm (1 ½") Projection Brackets
Picture Code Description Quantity Unit
0-154-TU-500XX | 2" (50 mm) Aluminum Tube 0-154-TU-500XX 2" (50 mm) Aluminum Tube
 FT
0-154-PE-XXX01 | End Plug for Euro Brackets 1½" (38mm) 0-154-PE-XXX01 End Plug for Euro Brackets 1½" (38mm)
 1 EA
0-154-PB-E04XX | EURO Medium Bracket | Large TM | 2" (50mm) Projection 0-154-PB-E04XX EURO Medium Bracket | Large TM | 2" (50mm) Projection
 1 EA
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 1 EA
0-154-PC-E01XX | Cover for EURO Medium Bracket 0-154-PC-E01XX Cover for EURO Medium Bracket
 1 EA
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 1 EA
0-154-PA-0XX03 | Rollux 50mm Smooth Tube Adapter for VTX20 0-154-PA-0XX03 Rollux 50mm Smooth Tube Adapter for VTX20
 1 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
EURO Medium Bracket | HM | 2" (50mm) Projection
Option 1: 32mm (1 ¼") Tube Hook Mount
Picture Code Description Quantity Unit
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 2 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
0-154-PC-001XX | Cover for CUB Medium Bracket 0-154-PC-001XX Cover for CUB Medium Bracket
 2 Ea
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 2 EA
0-154-TU-320XX | 1 ¼" (32 mm) Aluminum Tube 0-154-TU-320XX 1 ¼" (32 mm) Aluminum Tube
 1 FT
0-154-PE-XXX02 | End Plug for Euro Brackets 1¼" (32mm) 0-154-PE-XXX02 End Plug for Euro Brackets 1¼" (32mm)
 1 Ea
Option 2: 38mm (1 ½") Tube Hook Mount
Picture Code Description Quantity Unit
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 2 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
0-154-PC-001XX | Cover for CUB Medium Bracket 0-154-PC-001XX Cover for CUB Medium Bracket
 2 Ea
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 2 EA
0-154-TU-380XX | 1 ½" (38 mm) Aluminum Tube 0-154-TU-380XX 1 ½" (38 mm) Aluminum Tube
 1 FT
0-154-PE-XXX01 | End Plug for Euro Brackets 1½" (38mm) 0-154-PE-XXX01 End Plug for Euro Brackets 1½" (38mm)
 1 EA
Option 3: 45mm (1 ¾") Tube Hook Mount
Picture Code Description Quantity Unit
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 2 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
0-154-PC-001XX | Cover for CUB Medium Bracket 0-154-PC-001XX Cover for CUB Medium Bracket
 2 Ea
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 2 EA
0-154-TU-452XX | 1¾" (45mm) Tube (Two Channels) 0-154-TU-452XX 1¾" (45mm) Tube (Two Channels)
 1 FT
0-154-PA-XXX01 | End Plug Adapter for 1 3/4" (45mm) Tube 0-154-PA-XXX01 End Plug Adapter for 1 3/4" (45mm) Tube
 2 EA
Option 4: 32mm (1 ¼") Tube Tab Mount
Picture Code Description Quantity Unit
0-154-PB-E04XX | EURO Medium Bracket | Large TM | 2" (50mm) Projection 0-154-PB-E04XX EURO Medium Bracket | Large TM | 2" (50mm) Projection
 1 EA
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 1 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
0-154-PC-E01XX | Cover for EURO Medium Bracket 0-154-PC-E01XX Cover for EURO Medium Bracket
 2 EA
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 2 EA
0-154-TU-320XX | 1 ¼" (32 mm) Aluminum Tube 0-154-TU-320XX 1 ¼" (32 mm) Aluminum Tube
 1 FT
0-154-PE-XXX02 | End Plug for Euro Brackets 1¼" (32mm) 0-154-PE-XXX02 End Plug for Euro Brackets 1¼" (32mm)
 1 Ea
Option 5: 38mm (1 ½") Tube Tab Mount
Picture Code Description Quantity Unit
0-154-PB-E04XX | EURO Medium Bracket | Large TM | 2" (50mm) Projection 0-154-PB-E04XX EURO Medium Bracket | Large TM | 2" (50mm) Projection
 1 EA
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 1 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
0-154-PC-E01XX | Cover for EURO Medium Bracket 0-154-PC-E01XX Cover for EURO Medium Bracket
 2 EA
0-154-PC-E00XX | Cover for EURO Small Bracket with 1½" (38mm) Projection 0-154-PC-E00XX Cover for EURO Small Bracket with 1½" (38mm) Projection
 2 EA
0-154-TU-380XX | 1 ½" (38 mm) Aluminum Tube 0-154-TU-380XX 1 ½" (38 mm) Aluminum Tube
 1 FT
0-154-PE-XXX01 | End Plug for Euro Brackets 1½" (38mm) 0-154-PE-XXX01 End Plug for Euro Brackets 1½" (38mm)
 1 EA
Option 6: 45mm (1 ¾") Tube Tab Mount
Picture Code Description Quantity Unit
0-154-PB-E04XX | EURO Medium Bracket | Large TM | 2" (50mm) Projection 0-154-PB-E04XX EURO Medium Bracket | Large TM | 2" (50mm) Projection
 1 EA
0-154-PB-E03XX | EURO Medium Bracket | HM | 2" (50mm) Projection 0-154-PB-E03XX EURO Medium Bracket | HM | 2" (50mm) Projection
 1 EA
0-154-PS-ES0LX | Euro Idler End Support Set 0-154-PS-ES0LX Euro Idler End Support Set
 1 Set
0-154-PS-ES0RX | Euro Idler End Support Set for Right Side 0-154-PS-ES0RX Euro Idler End Support Set for Right Side
 1 Set
0-154-PC-E01XX | Cover for EURO Medium Bracket 0-154-PC-E01XX Cover for EURO Medium Bracket
 2 EA
0-154-PC-003XX | Screw Cover for EURO Medium Bracket 0-154-PC-003XX Screw Cover for EURO Medium Bracket
 2 EA
0-154-TU-452XX | 1¾" (45mm) Tube (Two Channels) 0-154-TU-452XX 1¾" (45mm) Tube (Two Channels)
 1 FT
0-154-PA-XXX01 | End Plug Adapter for 1 3/4" (45mm) Tube 0-154-PA-XXX01 End Plug Adapter for 1 3/4" (45mm) Tube
 2 EA

Certificates

Aitex
Vertilux 5 Years Warranty
Vertilux 10 Years Warranty
USGBC
Proposition 65 Compliant
Allergy Standards Verified Component
